5 Frames with a Leica Summicron DR 50mm f/2 on a Leica M240 – By Steven Bleistein

August 5, 2021

The first lens I procured for my Leica M3 body was a 1958 Summicron 50mm f/2 Dual Range (DR). The Dual Range is unique among Leica 50mm Summicrons because it allows for close range focusing down to 0.478m as opposed newer models which focus down to no less than 0.7m. To achieve the close-up range, the DR is paired with detachable optics that not only optimize the magnification of the finder for close range, but also correct the angle of view and so adjust for parallax.

Ken Rockwell has a nice write-up on the Summicron DR here if you are curious to know more. I’ve written about using the Summicron DR with a Leica M3 for 35mmc here.

In short, the Summicron DR is a marvel of engineering and design. Beyond its functionality, the Summicron DR’s styling evokes a sense of a golden age of Leica that has since passed, and never quite returned. The lens exudes sturdiness and quality, and feels hefty in the hand weighing in at a whopping 339g ‘(391g with the optics), heavy by Leica standards.

Yet despite all its merits, the Summicron DR is often given short shrift, and tends to sell for less than more recent Summicron 50’s. Optically, it is not quite as sharp. Yet on film this matters little. The lens is still plenty sharp, and I have noticed the lens produces a kind of photographic essence, which if not given away by an obviously contemporary artefact in the frame, you would mistake for an image from six decades ago in a way that the more recent Summicrons don’t.

Also, because of the mechanics of its dual range optics the Summicron DR  is not compatible with all Leica M bodies. Apart from the M3 for which the lens was made, the DR works fine with the M2, M4, M5, and M6. However, on the M6 TTL and M7, only the main range will work whereas the close range optics don’t mount properly. On the M9, apparently (link for more info) the close range won’t work at all and the main range works only 1-4m. I could find no information on using the DR with a Leica MP or a Leica M-A, but perhaps someone with experience could post a comment.

As for the M10, I assume that the even if you can mount the lens, the close range optics won’t work because of the M10’s thick lens mount bezel, a design compromise made by Leica in order to make the M10 body thinner than the previous digital M bodies. The unfortunate result of that compromise is that the M10 is not backwards compatible with all Leica lenses with add-on optics including the Summicron, Summilux, and Summaron 35mm lenses and probably some others too.

Leica warns that the Summicron DR is one of a handful of vintage Leica lenses that is not compatible at all with the digital Leica M240, but this is only half true. The DR will not mount on the M240 when it is set to the main range. If you try, it won’t twist into place. Pity the photographer who tries force it! Yet when set to close range, the DR mounts on the M240 just as smoothly like it should, and attaching the optics is no problem.

So is it worth it to buy a Summicron DR?

Well, that depends on what is important to you. If you own an M3, M2, M4, M5, or M6 body, why not? It is a beautiful lens and you can use both the main and close-up ranges.

On the M6 TTL and M7 you can use only the main range, but not the close range. You can usually find the Summicron DR sold without the optics for a lower price than with the optics. So if you want a vintage Summicron and you don’t care about missing out on the close range option—like every other Summicron 50mm out there–then fine. The DR is a great deal!

The M9 limitations on both the close and main ranges, for me at least, would be a deal breaker.

And what about the M240? The Summicron DR is no problem as long as you are OK with using it only as a close range lens–that is to say 0.478mm to 0.88m.

Now I had already owned my DR for use with my M3 when I bought my M240, but would I have bought the DR to use with my M240 only at close range if I did not also own an M3, M2, M4, M5, or M6? Probably not. You however might decide differently.

I shot all the photos in this piece with my Leica M240 and a Summicron 50mm f/2 set to close range.

I am a street photographer who lives in Japan. If you would like to see more of my work, have a look at my website bleisteinphoto.com, or my Instagram @sbleistein.

Support 35mmc

For as little as $1 a month, you can help support the upkeep of 35mmc via Patreon. Alternatively, please feel free to chuck a few pennies in the tip jar via Ko-fi:

Become a Patron!

Learn about where your money goes here.
Would like to write for 35mmc? Find out how here.

15 Comments

  • Reply
    Will
    August 5, 2021 at 3:18 pm

    You’re correct, the Summicron DR doesn’t work on the M9. The cams somehow aren’t compatible, which was a huge bummer after I bought an M9 to share lenses with my M4.

    I’ve since purchased an MP, and the DR works just fine with it, though the goggles need to have the stabilizing pin (next to the rangefinder magnifier) removed in order to sit on the body. Otherwise, perfectly compatible!

  • Reply
    John Squillace
    August 5, 2021 at 4:08 pm

    Hi, Steven – very nice article and photos and an excellent reference guide – thanks so much!

  • Reply
    Kodachromeguy
    August 5, 2021 at 4:11 pm

    What beautiful examples, Steven! Indeed, this DR lens is a gem in every way.

    If I can add a note for a potential buyer: The optical unit can separate from the focus mount. If you buy a used lens, make sure that the serial number on the optical part matches the serial number on the focus mount.

    • Reply
      Steven Bleistein
      August 5, 2021 at 11:55 pm

      I’m not able to find a serial number on the optical mount, unless I am not looking in the right place. I actually have two optical mounts–purely by accident–and both seem to work fine on the same lens. What makes you recommend matching serial numbers?

      • Reply
        Kodachromeguy
        August 6, 2021 at 6:00 am

        The focal length of the lens optical unit is matched to the focus mount. Look at the top of the optical unit and you will see tiny numbers; these show the exact focal length. The serial number is engraved in the focus unit is in the brass barrel. Its in there somewhere.

  • Reply
    Kurt Ingham
    August 5, 2021 at 4:32 pm

    Well written and informativewith nice illustrations-thanks!

  • Reply
    Daniel Fjäll
    August 5, 2021 at 8:21 pm

    I didn’t think I’d use the close up attachment at first when acquiring the lens. It gets used surprisingly often if you make sure you bring it with you. The DR does indeed work with the M-A as well as the MP. Great write up!

  • Reply
    Rory Jacobs
    August 6, 2021 at 12:58 pm

    I have the 50mm Summicron F/2 DR (with goggles) and use it with my Leica M10. It works great on the M10 in the close focus range as well as the ‘normal’ range.

    The only caveat on the M10 is that it wont’t focus a hair before infinity. There is some resistance at that point which would be ill advised force past.

    Thanks for the overview Steven

  • Reply
    Sergio
    August 8, 2021 at 10:22 pm

    Thanks Steven for this info, I was afraid to try this combo.

  • Reply
    Sergio
    August 8, 2021 at 10:25 pm

    Thanks Steven for tjis info, I was afraid to try this combo.
