Point & Shoot Scale Focus

The Cosina CX-2 – an ingenious bit of industrial design

I’ve been intrigued by the Cosina CX-2 on and off for a while. It was supposedly the inspiration for the Lomo LC-A, a camera that I like a lot, but sometimes feel a little bit disappointed at the quality of the results. The Cosina CX-2 is said to have a better lens, yet in other ways is a very similar camera to shoot. So after a short flirtation with an Olympus XA that decided to brick on me on its first outing, I thought I’d give one a go.

The Cosina CX-2 is a very pocketable, scale focus, manual advance, autoexposure point & shoot camera. It has a 35mm f/2.8 lens, a self-timer, and an aperture control for setting the aperture when using the flash (it fixes the shutter speed to the flash-sync speed). It also has a manual exposure index control which goes up to 400, but apart from that, as I say, exposure is automatic. In other words, it’s a very simple camera – yet despite this, it manages to be a quite ingenious but of industrial design.

The eccentric lens cover

The design of the Cosina CX-2 is ever so slightly eccentric, and yet in many ways is also better thought out than it’s most obvious competition. Like the XA series and Lomo LC-A, it has a manually operated lens door that when actioned switches the camera on. The XA has the sliding front door, the Lomo LC-A has a little switch the when switched reveals the lens and viewfinder. Both are quite neat, but neither are as satisfying or as beneficial to the user experience as the Cosina CX-2.

At first glance, the front cover of the Cosina CX-2 might seem a touch over-engineered. The whole front part of the camera rotates around the lens. Rotating it reveals the viewfinder window at the top of the camera, opens a hatch to reveal the lens in the middle, and reveals the manual focus control dial that’s located at the bottom-front-edge of the camera. On my particular copy, this all feels very smooth and well-engineered – it’s plastic of course, but it doesn’t feel in any way cheap.


.

The viewfinder

The viewfinder in my Cosina CX-2 is a little hazy. It’s perfectly useable, but it’s certainly not crystal clear – I suspect the many of these cameras will have suffered this fate by now. The viewfinder itself has frame lines with a parallax correction mark, two information lights, and a set of scale focus diagrams along the bottom.

The green light confused me to begin with as it lights up just to inform you that the battery is ok. I’d prefer a separate battery check feature – the green light glaring in the viewfinder every time you half-press just feels a little over the top for this level of information. The red lamp lights up to tell you when the required shutter speed drops below 1/60th, which is much more useful.

Focusing the Cosina CX-2

The ingenious thing about the rotating front cover design is simply its shape. When closed, it covers all the important parts of the camera, including the focus control lever, thus preventing it from being adjusted by accident even when the camera is pocketed. As well as this, when the cover is rotated, a good amount of space opens up around the focus control lever. This means that when using the camera, focusing doesn’t feel too fiddly at all, even with the camera to the eye – which is quite a feat for such a small bit of kit.

Distances are indicated within the viewfinder via the standard diagrams – head and shoulders for 0.9m, two people for 1.5m, three people for 3m, and mountains for infinity. Each of the marked distances has a slight click stop on the focus lever, though these clicks are light enough that intermediate distances can be selected with ease too.

The focus scale on the bottom of the camera also has marked distances of 0.9m, 1.5m, 3m and infinity. With the camera to your eye, it’s therefore easy enough to relate these distances to the scale in the viewfinder. For example, if you think your desired focus distance is about 2m, you can set it to between the two people setting and the three people setting and with some confidence, know that you’ll be around the 2m mark. This might sound obvious, but the Cosina CX-2 makes it feel obvious, which is a big part of what also makes it feel so useable.

In fact, I would go as far to say that thanks to the well-implemented focus lever, and focus scale inside the viewfinder, it’s probably one of the easiest manual focus cameras of this sort of size to focus with the camera to the eye. It might lack the rangefinder that’s found in the Olympus XA, but the symbols in the viewfinder are pretty much as useful as the very vague indication the XA’s short base length rangefinder gives anyway. The focus control found on the CX-2 has a longer throw with more space around it compared to the XA too.

Cosina CX-2 vs Olympus XA

Finally, if you prefer to preset the focus distance before raising the camera to your eye, additionally to the distance scale by the focus control lever, there is also a little window that shows the same diagrammatical scale that’s visible in the viewfinder.

With this little window being on a surface of the camera that faces up to the user, the Cosina CX-2 feels more intuitive to shoot than the LC-A and Olympus XA2/3/4 too. Unlike all of those cameras which have more fiddly focus scales to the side of the lens, with the CX-2 you can easily glance down at the camera, adjust focus, then bring it to your eye and quickly shoot without needing to move your hands from the way you hold it to shoot.

Focus controls on the side of the Lomo LC-A and XA4

Quiet Function

Another key advantage of the Cosina CX-2 feature set is its quiet function. The smoothly rotating front cover barely makes a sound at all. Thanks to it being manual focus, there’s no annoying lens noises. There’s also no noisy motorised film advance to contend with. The shutter is a tiny leaf shutter that – despite not the being quietest I’ve heard – is still very unobtrusive… That being said, there was something about the sound of the shutter that did put me off a little in use.

Manual film advance

When I first got my Cosina CX-2 and set about making sure it worked, I must admit I wasn’t filled with confidence. In fact, this feeling remained until I got my first photos back and found them to be perfectly well exposed.

Despite the quietness of the shutter, the noise it makes sounds a little cheap, with certain speeds creating a crappy sounding reverberation inside the camera. I also sometimes doubted that it was even shooting at different speeds which made me worry- despite the glaring green light in the viewfinder – that the battery might be dead. None of this is a big deal really, but whilst out shooting it there was at least one occasion where my confidence in it was reduced to the point that I felt I needed to look at the shutter when it was firing to make sure something useful was actually happening… hence this rather fetching (even if I do say so myself) selfie (I’m not sure what I am doing with my mouth, either…):

Cosina CX-2

The results

All my concerns about the shutter were alleviated when I got the negs back and found them to be fairly evenly exposed across the frames. My first response to the first few frames was positive too – they seemed to be a little sharper than the LC-A… not to mention the relief in finding that I’d not missed focus too many times.

Cosina CX-2

Cosina CX-2

Cosina CX-2

That said, as I went through them I began to find myself a little less impressed than I’d hoped. In some of the images, I could see what looked like a bit of haze or muck in the lens. You can see the contrast around the chains is lower than it should be here:

Cosina CX-2

At this stage, I did two things. The first was to inspect the lens with a bright light and the shutter open. The next was to message Stephen from Kosmo Foto, as I know him to be a fan of this camera. My bright light test proved there to be a good bit of dust inside the lens, and perhaps even what looked like a couple of smudges on one of the internal surfaces.

Stephen got back to me too. This is what he said:

Yes, it does look like there’s something not quite right with your lens there. Also, there’s no reason why you can’t shoot black-in-white in a Cosina CX-2, but it’s not really making the most of the experience. It’s a bit like spending your stag night in a library.

The Cosinon lens, like the Minitar lens at the heart of the Lomo LC-A, works best with lots of light and lots of colour. There’s no accident that the Lomography movement, which indirectly owes its existence to the CX-2, urged followers to try techniques like cross-processing slides in negative chemicals, which creates extra contrast and saturated colours. This is the CX-2’s sweet spot. Here are a few photos that demonstrate my point:

In bright sunlight, you could also try a more contrasty, 100-speed black-and-white film, something which also benefits from the Cosinon’s contrast-friendly personality. Now, if only knew someone who sold a 100-speed black-and-white film

I can see what he’s saying, but actually, I quite like some of my cloudy-day black and white photos. I can also see that were the lens not be in need of a clean, they would have come out a fair bit better.

Cosina CX-2

That being said, even with the specific issues with my camera, I can see that the Cosina CX-2 lens isn’t exactly perfect – in the lower part of the frame here you can see the edges of the frame are quite soft/smudgy:

Cosina CX-2

Bokeh is definitely toward the more “lively” end of the spectrum:

Cosina CX-2

It also vignettes a great deal – I assume the camera must have chosen a wider aperture here:

Cosina CX-2

These rings of flare/internal reflections are good fun too:

Cosina CX-2

In short, even cleaned, I’m not sure how much better than the Lomo LC-A the Cosina CX-2 lens really is. It’s certainly not up there with the Olympus XA lens, which is a bit of a shame considering how much more I enjoyed the user experience compared to those cameras.

Skip to the end

To a certain degree, my discovery that the Cosina CX-2 lens isn’t up there with the likes of the lens in the Olympus XA is a little bit of a disappointment – having owned 3 or 4 XAs that have either all failed on me, or have come to me broken, I was quite looking for an excuse not to try and find another… (and yes, I do continue to ignore my own advice)

That being said, my experience of shooting the Cosina CX-2 has nonetheless been very enjoyable – and to a certain degree wasn’t even let down by finding out that my particular lens is in need of a bit of TLC. Even in perfect condition, the lens might only be slightly better than the one found in the Lomo LC-A that copied it, but the camera itself is a much more enjoyable camera to shoot! From an industrial design point of view, the Cosina CX-2 genuinely is a wonderful thing, and something that I have therefore enjoyed exploring even if the outcome hasn’t been quite as I hoped! In fact, I think I would even go as far to argue that it’s probably the best-designed camera in its class! And of course, if you can make the lens work for you as Stephen does, then you’re definitely on to a winner!

You can find more photos from me here, and (loads more) from Stephen here
